Drone M690 Pro
The M690 Pro quadcopter is long endurance and multi-functional flight platform
| Category: | Drones |
|---|
M690Pro Overview
M690PRO, a long-endurance and multi-functional flight platform. M690Pro could fly up to 55 minutes(1kg payload) for easy mission accomplishment with abundant time. User-friendly PMM and flexible mounting methods guarantee its compatibility with various devices.
Thanks to the long effective communication distance, excellent protection rate, and portable backpack design, you can shuttle in different environments leisurely. The frames are specifically developed for the designated propulsion system and can reach extremely long flight times with low weight and high endurance.
| TECHNICAL PARAMETERS | |
|---|---|
| Model | M690Pro |
| Wheelbase | 700mm |
| Weight of Drone (Without Battery) | 1.69kg |
| Weight of Drone (With Battery) | 3.59kg |
| Weight of Battery |
Standard Smart 6S 22AH battery*1PC : 2.18kg |
| Max Take-off Weight | 6kg |
| Maximum Ascent Speed | 5m/s |
| Maximum Descending Speed | 3m/s |
| Maximum Horizontal Flight Speed | 20m/s |
| GPS Hover Accuracy | Vertical:±0.2m; Horizontal:±0.1m |
| Hover Time | 1kg≥55mins; 2kg≥40mins |
| Protection | IP54 |
| Maximum Tolerable Wind Speed | 14m/s |
| Working Temperature | -15℃~50℃ |
| Propulsion System | T-MOTOR |
| Control System | Pixhawk (not included) |
| Dimensions(Unfolded) | 550*550*445mm(Without Props) |
| Dimensions Folded | 283*278*175mm(With Landing Gear,Without Props) |
| Packing Size | 420*370*280mm(Normal); 510*420*340mm(With Package) |
| Shipping Weight | 6.6kg(With Packaging) |
